Waveplate

Waveplates (retardation plates or phase shifters) are made from materials which exhibit birefringence. The velocities of the extraordinary and ordinary rays through the birefringent material varies inversely with their refractive indices. This difference in velocities gives rise to a phase difference when the two beams recombine.

  • Product Origin:

    China
  • Order(MOQ):

    10
  • Shipping Port:

    Fuzhou, China
  • Lead Time:

    4 weeks
Share To : f t y b l ins
  • Product Detail

Half Waveplate

A half waveplate rotates linearly polarized light to any desired orientation. The rotation angle is twice the angle between the incident polarized light and the optical axis. Therefore, the half waveplate can be used as a continuously adjustable polarization rotator. The half waveplate is used to rotate the plane of polarization, electro-optic modulation and as a variable ratio beamsplitter when used in conjunction with a polarization cube.


Quarter Waveplate

When linearly polarized light is input at 45deg to the axis of a quarter waveplate, the output is circularly polarized, similarly, input circularly polarized light is transformed into linearly polarized light. The quarter waveplate is used in creating circular polarization from linear or linear polarization from circular, ellipsometry, optical pumping, suppressing unwanted reflection and optical isolation.


Types of Waveplate

Type



Feature

Zero Order

Cemented

Cemented by glue;Better Temperature Bandwidth;Wide Wavelength Bandwidth;Moderate damage threshold

Optical Contacted

No glue;Better Temperature Bandwidth;Wide Wavelength Bandwidth;Better damage threshold;Good wavefront and parallelism

Air Spaced

No glue, Mounted;Better Temperature Bandwidth;Wide Wavelength Bandwidth;High damage threshold

True Zero Order

Cemented

Cemented by glue;Better Temperature Bandwidth;Wide Wavelength Bandwidth;Moderate damage threshold;Excellent retardation performance

Single Plate

Single plate;Better Temperature Bandwidth;Wide Wavelength Bandwidth;High damage threshold;Only 1310nm, 1550nm available

Multi Order

Low Temperature Bandwidth;Low Wavelength Bandwidth;High damage threshold;Low cost

Dual Wavelength

Provide Specific Retardance At Two Different Wavelengths

Achromatic

Better Temperature Bandwidth;Very broad Wavelength Bandwidth;Cemented and air spaced available
